Thông tin chi tiết
Tiêu chuẩn và Giao thức
IEEE 802.3、IEEE 802.3u、IEEE 802.3ab、IEEE 802.3af、IEEE 802.3at
Chỉ số
5*Link/Act per device
4*PoE per device
1*Power per device
4*PoE per device
1*Power per device
Giao diện
4 10/100Base-Tx ports(Data/Power)
10/100Base-Tx port(Data)
10/100Base-Tx port(Data)
Cổng
Lightning Protection: 6KV
Lưu trữ & Chuyển tiếp
Yes
công suất trao đổi
1 Gbps
Tốc độ chuyển tiếp gói tin
0.744Mpps
Bảng địa chỉ MAC
2K
Quản lý nguồn cung cấp PoE
Port 1 to Port 4 support IEEE802.3at/af PoE standard
PoE through pin
1 2 4 5 +，3 6 7 8 -
Ngõ vào nguồn
AC：100-240V～ 50/60Hz
Kích thước
100*100*26mm ( W x D x H )
Tiêu thụ điện năng
in full configuration：<63W
PoE Max Power Supply：58W
PoE Max Power Supply：58W
Tính năng cổng
Standard: the switch functions as a common unmanaged switch and all the ports of the switch can communicate with each other.
Extend Mode: If the extend mode is enabled, the transmission distance of both power and data will extend up to 250m(10Mbps), this funcation can replace the extender and parts of the Fiber. It will extend the distance of the whole system and save the cost of the project.
Extend Mode: If the extend mode is enabled, the transmission distance of both power and data will extend up to 250m(10Mbps), this funcation can replace the extender and parts of the Fiber. It will extend the distance of the whole system and save the cost of the project.
Môi trường
Operating Temperature: 0℃~40℃ (32℉~104℉)
Storage Temperature: -40℃~70℃ (-40℉~158℉)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
Storage Temperature: -40℃~70℃ (-40℉~158℉)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
